zTrack - GPS Tracker via LoRa

Use cases

Possible Applications of zTrack

Vehicle Tracking

With zTrack you can track the routes of bikes, motorbikes, cars, trucks and even boats.

Fleet Tracking

Crew and vehicles of fleets can be easily tracked, therefore crew optimization of e.g. police- and fire department can be supported.

Pets, Animals

Never miss any step of your beloved pet with zTrack attachted to it’s collar.

Child care

You will never need to worry about where your child is, zTrack helps you to watch over them.

Elderly and Disabled people

For those who are in need, zTrack can be of help by delivering information about reaching a certain destination.

Parcels, bags

Just put zTrack in your bag, and be never affraid of losing it.

Valuable Items

Just as in the case of your packages, just find a way to attach zTrack to your valuable items so you don’t need to worry about it’s whereabouts.

About Us

About the Developement Team in short

zTrack LoRa GPS tracker developed by ZANE Systems

The zTrack LoRa GPS tracker is developed by ZANE systems Kft. Our company is located in Hajdusamson, Hungary. Our experienced hardware and software development team has more than 20 years experience in electronics development. We got to know LoRa technology in 2016 spring. Since then our products, which are adopt the LoRa technology, are used in Smart City applications, industrial machines, consumer electronics.

TECHNICAL DETAILS

LoRaWAN™ is a Low Power Wide Area Network (LPWAN) specification intended for wireless battery operated Things in regional, national or global network.
Long range, low power, and high network capacity.
LoRa technology is ideal for battery-operated sensors and low power applications such as IoT, M2M, Smart City, Sensor networks, Industrial automation, and more.

zTrack Mini
Dimensions: 60x20x15mm
Weight: 20g
Built in battery: 3.7V 250mAh LiPo
Charging: automatic through USB cable, charging time is approx. 1h
Operating time: depends on logging frequency, 4-40days

zTrack Midi
Dimensions: 70x33x23mm
Weight: 80g
Built in battery: 3.7V 2600mAh

Operation of a zTrack device
The module has an accelerometer and a temperature meter inside. The accel chip is able to detect if the unit is moving. If no movement detected, the tracker sends packets to the gateway in every 15 mins. When movement detected, the tracker changes the sending period to 30 seconds. If the GPS is able to locate the device, the position and the battery voltage will be sent in every communication attempt. If the GPS has no coordinates, the module will send only the battery level and temperature.

The zTrack has 250mAh built in Li-Po battery. This energy is enough to send 1000 messages with GPS coordinates. The tracker has built in accelerometer to detect movement. The device is using the GPS if motion detected. The sending frequency is adjustable by user from zTrack system. A typical usage is 4 hours motion daily, 5 min sending period. In this case the zTrack can work up to 2 weeks. The charging is possible by uUSB cable. The charging time is typically 1 hour.

Our hardware distributor is Chipcad Kft. For high quality and secured communication, we use Loriot.io's network infrastructure.

We created a demo application for our device. If you are LoRa system integrator and purchase zTrack then you will enjoy our free application for 3 months. Please help us developing zTrack by testing the device. Your feedbacks and suggestions are highly welcome and much appreciated.

DEMO SYSTEM

Drop your message in case you are interested in zTrack.

Please note, you can use zTrack in your location only if you have LoRa network in range.

Accu capacity:
Log period in active time (min):
Log period in idle time (min):
Daily active time (h):
Estimated working time:	16 days
Calculate

a LoRa GPS tracker to see the routes you want to see
